Git Deploying a Bundled Angular 2 App using Angular CLI to Microsoft Azure

In this screencast I use the angular-cli tool for the first time to package an angular2 app for production before git deploying it to Microsoft Azure.


Angular CLI

The CLI is at the moment of writing in beta and very much still a work in progress. It’s an excellent tool imho for scaffolding a new project, components and services. In this screencast we ran the following commands:

  ng new PROJECT_NAME // creates a new project
  ng g component COMPONENT_NAME // creates a new component
  ng g service SERVICE_NAME // creates a new service
  ng build -prod // builds a production ready version
  ng serve -prod // serves a production ready version

The CLI allows you to do a lot more, I really recommend you to install it and play with it for yourselves.

  npm install -g angular-cli

Also make sure to check out their official github repo which serves as great documentation.

Git Deployment

In this screencast we took a couple of short cuts, we didn’t setup a full CI environment. We initialized a new git repository in the dist folder and pushed only that folder to azure, meaning we built it on our dev machine, big NO NO. The workflow we want would look something like this instead.

  1. We commit a code change.
  2. Agent gets the latest code and builds it.
  3. Tests are run on build agent.
  4. If tests pass, deploy the dist folder to a staging slot.

Nevertheless we still need to enable a git repository for our web app, here’s an excellent guide on how to do that, it basically takes you through the steps I did in the screencast. Basically from the dist folder:

  1. git init
  2. git add *
  3. git commit -m “Initial Commit.”
  4. git remote add azure GIT_CLONE_URL
  5. git push azure master

These commands should fire up an authentication dialog and once you’ve provided the credentials the files should be pushed to the site.


With these steps we’ve managed to create a production build of an angular 2 app and deployed it to Azure. We did it all with just a few command lines using the angular CLI which was pretty awesome. The CLI does lagg behind the release candidates and is a work in progress so please use with caution.

Until next time, have an excellent day!

Angular 2 Upgrading to new 3.0 Router

In this episode we upgrade the ng2play repo to leverage the new 3.0 router and implement a route guard to protect components that require authentication. Here’s the entire changeset, not that bloody considering the changes but this is also a very small application.


Defining Routes

With the old router we decorated our app component with the RouteConfig annotation to configure the routs.

    { path: '/', component: Todo },
    { path: '/about/:id', component: About },
    { path: '/profile', component: Profile}
  export class AppComponent { ... }

With the new router the routing configuration is no longer bound to a specific component, instead we make it accessible as a provider by exporting it as a const from a separate routes.ts file. Another essential change is that we need to remove the forward slash in the beginning when defining the path.

  import { provideRouter, RouterConfig } from '@angular/router';

  export const appRoutes: RouterConfig = [
    { path: '', component: Todo },
    { path: 'about/:id', component: About },
    { path: 'profile', component: Profile }

  export const APP_ROUTER_PROVIDER = provideRouter(appRoutes);

Wich we can pass in to the bootstrap function in boot.ts instead of passing ROUTER_PROVIDERS as we did earlier.

import {APP_ROUTER_PROVIDER} from './routes';

bootstrap(AppComponent, [

Route Parameters

A component that we route to can access information about route parameters, query parameters and URL fragments by something called, ActivatedRoute, which we can inject into the constructor. The key difference is that route parameters can be accessed through the params property as an Observable or by the snapshot property if subscribing for future changes is overkill. Here’s both ways in our about.ts component:

  import {Component, OnInit} from '@angular/core';
  import { ActivatedRoute } from '@angular/router';

    selector: 'about',
    template: `Welcome to the about page! This is the ID: {{id}}`
  export class About implements OnInit {
    id: string;

    constructor(private route: ActivatedRoute) {}

    ngOnInit() { = this.route.snapshot.params['id'];
        .map(params => params['id'])
          .subscribe(id => {
   = id;

Guarding routes

Previously we could prevent our components from activating for unauthenticated users by using the @CanActivate and @CanDeactivate annotations. The guarding logic could be put inside a callback function:

import {CanActivate} from '@angular/router';
@Component({ ... })
@CanActivate(() => tokenNotExpired())
export class Profile { ... }

This approach suffered from that we don’t have access to the applications dependency injection and that we need to decorate each component class with it. The new router solves these problems, we can easily create an auth-guard injectable service that we can pass in to the route configuration accordingly:

  import { provideRouter, RouterConfig } from '@angular/router';
  import { AuthGuard} from './auth-guard';

  export const appRoutes: RouterConfig = [
    { path: '', component: Todo },
    { path: 'about/:id', component: About },
    { path: 'profile', component: Profile, canActivate: [AuthGuard] }

  export const APP_ROUTER_PROVIDER = provideRouter(appRoutes);

The auth guard has access to the applications dependency injection and we can redirect the user to the root component if they are not allowed to navigate to the component.

import {tokenNotExpired} from 'angular2-jwt';
import { Injectable } from '@angular/core';
import {
} from '@angular/router';

export class AuthGuard implements CanActivate {
  constructor(private router: Router) {}

  canActivate(next: ActivatedRouteSnapshot, state: RouterStateSnapshot) {
    if (tokenNotExpired()) {
      return true;

    return false;

Let’s also not forget that we’ll need to pass the auth-guard to our bootstrap method to be able to resolve the dependency:

import {APP_ROUTER_PROVIDER} from './routes';
import {AuthGuard} from './auth-guard';

bootstrap(AppComponent, [


With these steps we’ve managed to migrate our application to the new 3.0 router, quite frictionless seemingly, but imho they started calling angular2 for RC way too early. It’s still moving too much to even consider using this for production anytime soon.

Until next time, have an excellent day!

Structured Logging with AspNet Core using Serilog and Seq

In this episode we take a first look at structured logging from an AspNet Core application using Serilog and Seq.


Adding Serilog

Configuring the web app to leverage serilog only requires 3 simple steps. First make sure to get the nuget packages by adding these lines to your packages.json.

    "Serilog.Extensions.Logging": "1.0.0-rc2-*",
    "Serilog.Sinks.RollingFile": "2.0.0-rc-*",
    "Serilog.Sinks.Seq": "2.0.0-rc-*"

In the constructor of your Startup.cs file, configure the logger to log to both the Seq endpoint and to a rolling file, or that’s at least what I did.

    Log.Logger = new LoggerConfiguration()
        .WriteTo.RollingFile("log-{Date}.txt", LogEventLevel.Information)

This assumes that you’ve installed the Seq MSI on your local machine, you can grab it from here. Finally, add serilog to the logger factory in the configure method.

public void Configure(IApplicationBuilder app, IHostingEnvironment env, ILoggerFactory loggerFactory)

That’s it, browse http://localhost:5341 and you should see the following:

Structured Logging

To log entire objects that will be queryable, simple pass an @-sign in front of the tag name that you want to create. For instance, to log a person object and create a tag accordingly from the HomeController we do the following.

public class Person
    public string Firstname { get; set; }
    public string Lastname { get; set; }

public class HomeController : Controller
    private readonly ILogger _logger;

    public HomeController(ILogger logger)
        _logger = logger;

    public IActionResult Index()
        var p = new Person { Firstname = "Ajden", Lastname = "Towfeek" };
        _logger.LogInformation("Just trying out the logger {@Person}", p);
        return View();

Which will result in the following queryable log post in Seq:


It’s really powerful to log information with rich, structured and queryable log data but there are also some downsides for the moment with using Seq that I’d like to point out.

  • Shipping logs over http/https adds extra overhead.
  • Seq Service needs to be installed on separate virtual machine than your Azure Web App (assuming you’re using Azure). Meaning you’ll need to pay for an extra VM just for logging.
  • Free license is only usable for development, can’t have open endpoints that anyone can log to in production.

Having that said, I still think the idea of structured logging is very interesting and it provides an extra dimension of information when fixing/reproducing bugs. I just won’t be using Seq in production just yet.

Until next time, have an excellent day!

Getting Started with Angular2 RC1 and AspNet Core 1.0 RC2 using VisualStudio 2015 and Gulp

In this weeks screencast we start on a new page, to create a new angular2 and aspnet core seed project using the latest release candidate versions. My earlier series contains many upgrade from beta x to beta y episodes, even alphas, it’s starting to become messy to follow, hence the file new project. Make sure to star the project on github, available at


Until next time, have an excellent day!

Upgrading to Angular 2 RC1 from beta – lessons learned

I recently upgraded my ng2 play repo from beta 15 to rc1 and I ran into a couple of things I thought would be nice to share since I’ve been getting quite a few mails about it.

angular2 -> @angular

To begin with all of the packages are now distributed under the @angular npm scope. This changes how Angular is installed via npm and how you import the code.

npm install --save @angular/core @angular/compiler @angular/common @angular/platform-browser @angular/platform-browser-dynamic rxjs@5.0.0-beta.6 zone.js@0.6.12

To import various symbols we needed to make the following adjustments:

  • angular2/core -> @angular/core
  • angular2/compiler -> @angular/compiler
  • angular2/common -> @angular/common
  • angular2/platform/browser -> @angular/platform-browser
  • angular2/platform/server -> @angular/platform-server
  • angular2/http -> @angular/http
  • new package: @angular/router replaces angular2/router with breaking changes

Loading with SystemJS

Instead of configuring and mapping libraries and modules in index.html we load the app a bit differently, see systemjs.config.js for details.

RxJS Deps

What isn’t mentioned in the angular2 changelog is that the RxJS version it uses has a new dependency to symbol-observable, make sure to install it.

npm install --save symbol-observable

and map it up in systemjs.config.js.

New Router (breaking changes)

In app.ts a couple of imports have moved, we now import LocationStrategy, HashLocationStrategy and Location from common instead of router:

import {LocationStrategy, HashLocationStrategy, Location} from 'angular2/router';
import {ROUTER_PROVIDERS, RouterOutlet, RouteConfig, RouterLink} from 'angular2/router';


import {LocationStrategy, HashLocationStrategy, Location} from '@angular/common';
import {ROUTER_PROVIDERS, ROUTER_DIRECTIVES, Routes, Router} from '@angular/router';

and we only pass ROUTER_DIRECTIVES to the components directive instead of RouterOutlet and RouterLink. Furthermore, we configure our routes with the Routes-attribute instead of RouteConfig and there is no ‘as’ property, meaning:

  { path: '/', component: Todo, as: 'Home' },
  { path: '/about/:id', component: About, as: 'About' },
  { path: '/profile', component: Profile, as: 'Profile' }


  { path: '/', component: Todo },
  { path: '/about/:id', component: About },
  { path: '/profile', component: Profile }

Router Parameters and no CanActivate

Here we have quite a few changes if we take a look in about.ts instead of resolving the params in the constructor from the RouteParams class we now need to implement OnActivate and get it in the routerOnActivate-method.

import { Router, RouteSegment, OnActivate } from '@angular/router';
export class About implements OnActivate {
  routerOnActivate(current: RouteSegment) { = current.getParam('id');

and in the view we now pass parameters using the routerLink like this:


instead of the previous syntax which was a bit more cumbersome imho:


We could previously prevent the component from loading with the CanActiviate-attribute, but there is no equivalent for that yet, see profile.ts.

For more changes see the breaking changes docs.

Cannot find name ‘Promise’

If you’re targeting ES5 and want to prevent errors such as:

  • Cannot find name ‘Promise’
  • Cannot find name ‘Map’
  • Cannot find name ‘Set’

You’ll need to reference es6-shim at the top of your main typescript file, the file that boots the app if you will, in my case it’s boot.ts. (syntax highlighter messes up the brackets below)


To be able to do so you’ll need to run the following commands:

npm install -g typings
typings install es6-shim --ambient

before you can reference the es6-shim typescript definition file.

Final words

Cool, that was a lot of changes, let’s see if they keep down the breaking changes from now on at least. I can’t shake the feeling that a lot of people feel that things are a lot more complicated now. I haven’t been able to answer all the emails, I’ve been busy with some new cool customer projects.

Upgrading material2 from alpha1 to alpha4 was seamless, I also cleaned up the loading in systemjs.config.js. Anyways make sure to star my ng2 play repo.

Until next time, have a nice day!

Azure Cloud Service Install Certificate Into Trusted Root Certificate Authorities Store with Azure Startup Task

Here’s a guide on how to install a certificate into Trusted Root Certificate Authorities store for Azure Cloud Services.

What we want to solve

In our case we had a web role (web app) that needed to communicate with a third party that we didn’t control, they were using a self signed certificate and required communication over HTTPS. For the TLS/SSL handshake to succeed we need to install the certificate into our trust store.

What others have done

There are solutions out there where people install the certificate using the portal into the personal store and then have a worker role move the certificate to the trusted CA store with administrative privileges at runtime. First of all, that’s a very cumbersome approach and second it uses resources that costs money, there is a much simpler way.


1. Include the certificate you want to install into your web app, optionally as a link.

2. Make sure to set the Build Action to Content and Copy to Output Directory to Copy if newer.

3. Add a startup.cmd also with Build Action set to Content and Copy to Output Directory set to Copy if newer.

4. Modify the contents of startup.cmd to the following:

certutil -addstore root certificate.cer

5. Open up ServiceDefinition.csdef and add the following lines to your web role configuration section.


Full context in our simple sample looks like this:

6. You’re done! Next time you deploy the cloud service the certificate will be installed into the Trusted Root Certificate Authorities store for the VM.

What _not_ to do

You can find answers on stack overflow and blogs on how to install the certificate manually by remoting to the machine and using mmc locally. That is a bad idea since it will be gone next time the VM is teared down and re-created. And if you’re new to Azure Cloud Services, that’s not strange at all, it happens.

Final Words

These 5 steps are super easy compared to many other proposed solutions out there. We learned about it from security expert Dominick Baiers blog post from a while back, it’s a lot shorter but as he states — the title says it all!

Hope it helped!

Angular 2 Material Replacing Bootstrap

In this weeks screencast we fully replace bootstrap with material components for angular 2. Material2 just announced their alpha 2 release, adding a bunch of components, perfect timing for live coding screencast, code at The ng2play repo has also been updated to the latest angular2 version which at the time of writing is beta 15, see the changelog for details.

During the coding session we integrate the following components into our app:

Make sure to check out the screencast below, enjoy!


Documentation / Demo App

There isn’t any official documentation for material2 yet, but there is a demo app in their github repo, here are the steps to get it up and running on your local dev machine:

  1. Make sure you have `node` installed with a version at _least_ 4.2.3.
  2. Run `npm install -g angular-cli` to install the Angular CLI.
  3. Clone the angular/material2 repo
  4. From the root of the project, run `npm install`, then run `npm run typings` to install typescript definitions.
  5. To build the project, run `ng build`.
  6. To bring up a local server, run `ng serve`. This will automatically watch for changes and rebuild.

After the changes rebuild, the browser currently needs to be manually refreshed. Now you can visit the prompted URL in your browser to explore the demo app.

Resouces on Angular Material

To learn more about material deisgn and components for angular, make sure to check out my pluralsight course Angular Material Fundamentals.

Until next time, have a nice day folks and keep on coding!

Angular 2 Material First Look

In this weeks screencast we take a first look at the material components for angular2 that just released their first alpaha, code at We’ll integrate the button and checkbox component into our ng2play repo, the idea is to fully replace bootstrap down the road.



There will be breaking changes between alpha releases, first release of angular2-material includes the following components:

To learn more about material deisgn and components for angular, make sure to check out my pluralsight course Angular Material Fundamentals.

Until next time, have a nice day folks!

Angular 2 Lifecycle Hooks

New screencast on Angular 2 beta 9, covering Lifecycle Hooks, get the code at


The Lifecycle Hooks

Directive and component instances have a lifecycle as Angular creates, updates, and destroys them. Here’s the complete lifecycle hook interface inventory, all of them available in the angular2/core library and called in the provided order.

  • OnChanges: Calls ngOnChanges – called when an input or output binding value changes
  • OnInit: Calls ngOnInit – after the first ngOnChanges
  • DoCheck: Calls ngDoCheck – developer’s custom change detection
  • AfterContentInit: Calls ngAfterContentInit – after component content initialized
  • AfterContentChecked: Calls ngAfterContentChecked – after every check of component content
  • AfterViewInit: Calls ngAfterViewInit – after component’s view(s) are initialized
  • AfterViewChecked: Calls ngAfterViewChecked – after every check of a component’s view(s)
  • OnDestroy: Calls ngOnDestroy – just before the directive is destroyed.

To learn more about lifecycle hooks, check out the official documentation here.

Until next time, have a nice day folks!

Angular Material Fundamentals Course at Pluralsight

Angular Material Fundamentals course released at pluralsight, make sure to check it out here,, course trailer below:

Hope you guys enjoy the course and learn a lot, and as always, have a nice day!
